FEATURES
•Locking clamp for positive locking of spindle.
•With standard setting ring .
•Standard setting rings are optional for other models.
•Display data is origin absolute measurement after changing battery.
•Origin starting zero point setting, clock, power on/off.
•Inch/mm conversion at any spindle position, abs. and inc. conversion at any spindle position.
•RS232 output port. Connecting cable: P1103 or P1104 (Optional)
•One SR44 cell. Power consumption<35μA. Auto power off.
•Alarm: low voltage, Counting value composition error
•Ratchet stop,ratchet stop and ratchet friction thimble or ratchet stop and friction thimble for constant measuring force.
•Resolution: 0.001mm(Metric); 0.00005"(Inch) |
